Package

3 in 1

LED type

3528

Pixel pitch

6mm

Density

27556dots/㎡

Module size

384X192（mm）

Pixel configuration

1R1G1B

Module density

64*32=2048dots

Weight of module

0.48kg

Best viewing distance

6m～50m

Best viewing angle

140°

Driving method

1/16Scanning

Frame frequency

≥60Hz

Brightness

1200cd/㎡

Ave power consumption

＜200W/㎡

Max power consumption

＜450w/㎡

Control method

Synchronization

Refresh frequency

≥1920Hz

MTBF

10,000H

Life span

100,000H

Out-of control point

＜0.0001
